Threaded Design Swivot - 3/4-10 X 3 - Extra Fine

Part Number: TBU-0755X3-S
Weight: 0 lbs 5 ozs
Thread - External: 3/4-10
Length - Thread: 3
Diameter - Contact Surface: 3/8
Degree Swivel: 40
Hex - Internal - Flat: 3/8
Diameter - Ball: 1/2
Ball Only Part No.: BUB-500-S
Load - Rating: 8,150
Tooth Pattern: EF

Part:TBU-0755X3-S

TBU-0755X3-S
